Description
Container Loading Ramp – Model BC-DOCKRAMP12T
Price: £8,999.00
The BC-DOCKRAMP12T container loading ramp is a heavy-duty, manual hydraulic ramp designed for efficient and safe container loading. Built with high-strength steel and a robust design, it supports up to 12 tons, making it ideal for warehouses, logistics centers, and freight yards.
-
Size: 11,150mm (L) x 2,100mm (W) x 1,100mm (H)
-
Platform: 7,000mm slope + 3,000mm platform + 700mm tail plate
-
Height Adjustable: 1,100mm to 1,800mm via manual hydraulic pump
-
Durable Construction: 5mm steel plate, 8mm steel mesh, solid tires (700-9)
-
Secure Design: 200mm guardrails, steel chain and hook for container attachment
-
Hydraulics: 2 powerful cylinders with 32Pma oil pipe
Finished in spray-painted blue (custom colors available), this ramp offers strength, safety, and flexibility. Weighing approximately 3,200kg, it’s a reliable solution for your heavy-duty loading needs.
Material: Full steel construction
Connectivity: Welded hook and steel chain for secure container attachment
Power: Manual pump and hand leg operated – no external power required
Perfect for sites that need portability and performance without compromising safety.
| 1 |
Model |
BC-DOCKRAMP12T |
| 2 |
Overall size (mm) |
11150(L)*2100(W)*1100(H) |
| 3 |
Platform size |
Slope length : 7000mm (L)
Platform plate length : 3000mm (L)
The tail plate length : 700mm
The tongue plate length : 400mm
Width : 2100mm
Steel plate thickness : 5mm
Steel mesh thickness : 8mm |
| 4 |
Load |
12T |
| 5 |
Distribution power |
Manual hydraulic pump, and hand leg |
| 6 |
Adjustable range |
1100-1800mm(H) |
| 7 |
Guardrail high |
200mm (40*60*3mm rectangular pipe) |
| 8 |
Main beam |
160*80*5mm rectangular pipe |
| 9 |
Vice beam |
100*50*4mm |
| 10 |
Hydraulic cylinder |
Φ80*Φ50(2 pcs) |
| 11 |
Hydraulic oil pipe |
32Pma |
| 12 |
Solid tire |
700-9 |
| 13 |
Container connectivity |
The bridge body is welded with a hook and fixed with a steel chain |
| 14 |
Paint Color |
Generally blue(adjustable); spray-paint |
| 15 |
Overall weight |
±3200kg |
| 16 |
material |
steel |
| 17 |
Price 12T |
£8,999.00 |
